DURABLE AGM BATTERY

UB Sealed Lead Acid Battery

UB Sealed Lead Acid Battery

Short Description:

• Maintenance Free • Lead Acid

UPBattery UB series Sealed free maintenance lead acid batteries are designed with AGM technology,high performance plates and electrolyte to gain extra power output for common power backup system applications widely used in the fields of UPS, Security and Emergency lighting system.

• Brand: UPBattery / OEM Brand for customers Freely
• ISO9001/14001/18001;
• CE/UL/MSDS;
• IEC 61427/ IEC 60896-21/22;

Need Battery Urgent?

You can contact us in any way that is convenient for you. We are available 24/7 via: sales@cssun.net or WhatsApp/WeChat: (+86)-13613021776

New Products

ULC Lead Carbon Battery

• Fast Charge • Lead Carbon

OPzV Tubular Gel Battery

Tubular OPzV • Deep Cycle UPBattery

UFT Front Access Gel Battery

• Front Terminal • Gel The

OPzS Flooded Lead Acid Battery

Short Description: • Flooded OPzS •

UB Valve Regulated Gel Battery

Short Description: • Maintenance Free •

UB Series SEALED FREE MAINTENANCE VRLA AGM BATTERY

Voltage: 12V, 6V
Capacity: 12V4Ah~12V250Ah; 6V4Ah~6V12Ah
Designed floating service life: 8-10 years @ 25 °C/77 °F.
Brand: UPBattery / OEM Brand for customers Freely

Certificates: ISO9001/14001/18001 ; CE/IEC 60896-21/22 / IEC 61427 /UL Approved

> Summary

UPBattery UB series Sealed free maintenance lead acid batteries are designed with AGM technology, high performance plates and electrolyte to gain extra power output for common power backup system applications widely used in the fields of UPS, Security and Emergency lighting system.

They are sealed and free maintenance whole life, valve regulated type standby AGM battery, also named by VRLA battery, SLA battery, and SMF battery.

> Features And Advantages For Sealed Free Maintenance Lead Acid Battery

30% more cyclic life through innovation at the PAM additives
Long life expectancy of 10 years in floating condition
Thick flat plate with high Tin low Calcium alloy
Wide operating temperature range from -15°C to 45°C
3% Low self-discharge rate
Very good deep cycle performance: up to 750 cycles @50% DOD
Excellent deep discharge recovery capability

> Construction For VRLA AGM Battery

Positive plate – Thick high Sn low Ca grid with special paste
Negative plate – Balanced Pb-Ca grid for improved recombination efficiency
Separator – Advanced AGM separator for high pressure cell design
Electrolyte – Dilute high purity sulfuric acid
Battery container and cover –Fire resistance ABS, water proof
Pillar seal – Two layers epoxy resin seal
Relief valve – Complete with integrated flame arrestor

> Charging Voltage And Settings For VRLA Battery

Constant voltage charging is recommended
Recommended float charge voltage: 2.27V/cell @20~25°C
Float voltage temperature compensation: -3mV/°C/cel l
Float voltage range: 2.27 to 2.30 V/cell @ 20~25°C
Cyclic application charge voltage : 2.40 to 2.47 V/cell @ 20~25°C
Max. charge current allowable : 0.25C

> Application For Sealed Free Maintenance Lead Acid Battery

Uninterruptible power supplies (UPS); Emergency Lighting Systems; Alarm Systems, Computers; Fire & security systems; Telecommunication systems; Inverter; Solar powered systems; Power Tools; Communication equipment; Electronic cash registers; Electronic test equipment; processor based office machines; Control equipment; Electric powered bicycle and wheelchairs; Geophysical equipment; Marine equipment; Medical equipment; Portable cine & video lights; Television& video recorders; Vending machines; Toys; Geophysical Equipment; Vending Machines ; Other standby or primary power supplies.

UPBattery Model	Nominal Voltage (V)	Capacity (Ah)	Dimension (mm)				Weight	Terminal	Bolt
UPBattery Model	Nominal Voltage (V)	Capacity (Ah)	Length	Width	Height	Total Height	kgs	Terminal	Bolt
Sealed Maintenance Free Lead Acid Battery 6V 12V
UB6-4.0	6	4/20HR	70	47	101	107	0.7	F1/F2/CUT	/
UB6-4.5	6	4.5/20HR	70	47	101	107	0.75	F1/F2/CUT	/
UB6-5	6	5/20HR	70	47	101	107	0.8	F1/F2	/
UB6-7.0	6	7/20HR	151	34	95	101	1.08	F1/F2	/
UB6-10	6	10/20HR	151	50	94	100	1.6	F1/F2	/
UB6-12	6	12/20HR	151	50	94	100	1.75	F1/F2	/
UB12-4	12	4/20HR	90	71	101	107	1.35	F1/F2	/
UB12-4.5	12	4.5/20HR	90	71	101	107	1.48	F1/F2	/
UB12-5	12	5/20HR	90	71	101	107	1.58	F1/F2	/
UB12-6.5	12	6.5/20HR	151	65	94	100	1.9	F1/F2	/
UB12-7.0	12	7/20HR	151	65	94	100	2.05	F1/F2	/
UB12-7.2	12	7.2/20HR	151	65	94	100	2.15	F1/F2	/
UB12-7.5	12	7.5/20HR	151	65	94	100	2.2	F1/F2	/
UB12-9	12	9/20HR	151	65	94	100	2.4	F1/F2	/
UB12-10	12	10/20HR	152	99	96	102	3.2	F1/F2	/
UB12-12	12	12/20HR	152	99	96	102	3.5	F1/F2	/
UB12-15	12	15/20HR	152	99	96	102	3.8	F1/F2	/
UB12-17/18	12	17/18/20HR	181	77	167	167	5.18	L1/M5	M5×16
UB12-20	12	20/20HR	181	77	167	167	6	T2	M5×16
UB12-24	12	24/10HR	166	126	174	174	7.7	T2	M5×16
UB12-26	12	26/10HR	166	175	126	126	8.3	T2	M5×16
UB12-35	12	35/10HR	196	130	155	167	10	T2	M6×16
UB12-38/40	12	40 /10HR	198	166	172	172	12.3	T2	M6×16
UB12-45	12	45/10HR	198	166	174	174	13	T2	M6×16
UB12-50	12	50/10HR	229	138	208	212	15.5	T3	M6×16
UB12-55	12	55/10HR	229	138	208	212	16.2	T3	M6×16
UB12-65	12	65/10HR	350	167	178	178	20.5	T3	M6×16
UB12-70	12	70/10HR	350	167	178	178	21.3	T3	M6×16
UB12-75	12	75/10HR	260	169	211	215	21.7	T3	M6×16
UB12-80	12	80/10HR	260	169	211	215	23.3	T3	M8×16
UB12-85	12	85/10HR	331	174	214	219	24.8	T3	M6×16
UB12-100C	12	100/20HR	307	169	211	216	26.5	T3	M6×16
UB12-100A	12	100/10HR	331	174	214	219	29	T4	M6×16
UB12-120B	12	120/10HR	407	173	210	233	33	T5	M8×16
UB12-120A	12	120/10HR	407	173	210	233	34	T5	M8×16
UB12-135	12	135/10HR	341	173	283	288	41	T5	M8×16
UB12-150B	12	150/20HR	484	171	241	241	41	T4	M8×16
UB12-150A	12	150/10HR	484	171	241	241	43.5	T4	M8×16
UB12-160	12	160/10HR	532	206	216	222	48.8	T4	M8×16
UB12-180	12	180/10HR	532	206	216	222	52.2	T4	M8×16
UB12-200B	12	200/20HR	522	240	219	225	55.3	T5	M8×16
UB12-200A	12	200/10HR	522	240	219	225	58.2	T5	M8×16
UB12-230	12	230/10HR	522	240	219	225	61	T5	M8×16
UB12-250	12	250/10HR	520	268	220	225	70	T5	M8×16
Notice : Products will be improved without notice, please contact UPBattery sales for specification in kind prevail.
